Jet-Powered UAV: FSI Training Package

$1,999.00 Internship

FSI analysis enables drone designers and manufacturers to examine high-stress regions in greater detail. This package reviews the following UAVs:

  • RQ-4
  • MQ-9
  • RQ-170
Click on Add To Cart and obtain the Geometry file, Mesh file, and a Comprehensive ANSYS Fluent Training Video.

To Order Your Project or benefit from a CFD consultation, contact our experts via email (info@mr-cfd.com), online support tab, or WhatsApp at +44 7443 197273.

There are some Free Products to check our service quality.
If you want the training video in another language instead of English, ask it via info@mr-cfd.com after you buy the product.
Categories: , , ,
Fsi

FSI Analysis for Northrop Grumman RQ-4 Global Hawk, ANSYS Fluent

  • The problem numerically simulates the Fluid-Structure Interaction over Northrop Grumman RQ-4 Global Hawk using ANSYS Fluent software.
  • The Global Hawk geometry was modeled using SpaceClaim and then imported into ANSYS meshing for meshing consisting of 5,056,067 non-conformal elements.
  • The simulation used a pressure-based solver.
  • One way FSI model analyses total strain, and stress over the turbine.
Fsi

MQ-9 UAV FSI Analysis: CFD Simulation by Ansys Fluent

  • The problem numerically simulates a MQ-9 UAV using ANSYS Fluent software.
  • We design the 3-D model with the SpaceClaim software.
  • We mesh the model with Ansys Meshing software. The element number equals 11,136,403 and their type is Tetrahedral.
  • In this simulation, Dynamic Mesh is used for FSI modeling.
Fsi

RQ-170 UAV FSI Analysis: CFD Simulation by Ansys Fluent

  • The problem numerically simulates a RQ-170 UAV using ANSYS Fluent software.
  • We design the 3-D model with the SpaceClaim software.
  • We mesh the model with Ansys Meshing software. The element number equals 19,537,805  and their type is Tetrahedral.
  • In this simulation, Dynamic Mesh is used for FSI modeling.

Special Offers For All Products

If you need the Geometry designing and Mesh generation training video for all the products, you can choose this option.
The journal file in ANSYS Fluent is used to record and automate simulations for repeatability and batch processing.
Editable geometry and mesh allows users to create and modify geometry and mesh to define the computational domain for simulations.
The case and data files in ANSYS Fluent store the simulation setup and results, respectively, for analysis and post-processing.
Geometry, Mesh, and CFD Simulation methodologygy explanation, result analysis and conclusion

Special Offers For Single Product

Get a FREE consultation to discuss running your simulations on our high-performance computing systems
If you need the Geometry designing and Mesh generation training video for one product, you can choose this option.
editable geometry and mesh allows users to create and modify geometry and mesh to define the computational domain for simulations.
The case and data files in ANSYS Fluent store the simulation setup and results, respectively, for analysis and post-processing.
Geometry, Mesh, and CFD Simulation methodologygy explanation, result analysis and conclusion
Enhancing Your Project: Comprehensive Consultation and Optimization Services
The MR CFD certification can be a valuable addition to a student resume, and passing the interactive test can demonstrate a strong understanding of CFD simulation principles and techniques related to this product.
The journal file in ANSYS Fluent is used to record and automate simulations for repeatability and batch processing.

Description

FSI Analysis: CFD Simulation Training Package for 3 Projects In One Package

This UAV CFD Analysis course focuses on Drone Fluid-Structure Interaction (FSI) Simulation using ANSYS Fluent. A critical consideration in drone design is the effect of fluid forces on the structure, particularly the resulting stress and displacement. Failure to account for these factors during the design and construction phases can prevent the product from obtaining the necessary safety approvals. Accordingly, identifying the location and magnitude of maximum stress is essential.

By preparing this package, you will gain acceptable information and training in the field of Fluid Structure Interaction (FSI). Also, if you need Simple Aerodynamic simulation, Acoustic or Stability Derivative Analysis, you can purchase another package that includes this simulation.

Our entire focus in this package is to teach you the best approach to configuring Fluent, extracting results, and analyzing data—skills that will help you analyze, design, and build UAVs. After completing this package, your perspective and performance in this field will change dramatically. The CFD simulation package includes 3 different projects using ANSYS Fluent, covering various UAVs and addressing Simple Aerodynamic Simulation, Acoustic Simulation, Stability Derivatives, and FSI Simulation for each UAV.

For each UAV, we’ve performed an FSI simulation using ANSYS Fluent. This package features different types of UAVs designed for tactical, reconnaissance, and mapping purposes. The devices covered in this training package are:

  • RQ-4
  • MQ-9
  • RQ-170

An effort has been made to select a variety of UAVs that differ in performance, operating altitude, length, wingspan, and other parameters, in order to represent a broad range of fluid-dynamic challenges.

Through this comprehensive training package, learners will develop the expertise required to model and analyze CFD simulations for Jet-Powered fixed-wing and their associated applications.
