UAV (Drone) Acoustic Analysis: CFD Simulation by ANSYS Fluent, 6 Projects

$349.00 $139.60 HPC

  • RQ-7 Shadow
  • RQ-11 Raven
  • ScanEagle
  • Skywalker-x5
  • Skywalker-x8
  • Bayraktar
Click on Add To Cart and obtain the Geometry file, Mesh file, and a Comprehensive ANSYS Fluent Training Video.

To Order Your Project or benefit from a CFD consultation, contact our experts via email (info@mr-cfd.com), online support tab, or WhatsApp at +44 7443 197273.

There are some Free Products to check our service quality.
If you want the training video in another language instead of English, ask it via info@mr-cfd.com after you buy the product.
Categories: , , , , , , ,
Rq-7

RQ-7 Shadow UAV Acoustic Analysis: CFD Simulation by Ansys Fluent

  • The problem numerically simulates an AAI RQ-7 Shadow UAV using ANSYS Fluent software.
  • We design the 3-D model with the Design Modeler software.
  • We mesh the model with Fluent Meshing software. The element number equals 5,449,057 and their type is polyhedra.
  • In this simulation, FW_H and BroadBand Noise are used for acoustic modeling.
Rq-11

RQ-11 Raven UAV(Drone) Acoustic Analysis: CFD Simulation by Ansys Fluent

  • The problem numerically simulates a RQ-11 Raven UAV using ANSYS Fluent software.
  • We design the 3-D model with the Design Modeler software.
  • We mesh the model with Fluent Meshing software. The element number equals 5,300,212 and their type is polyhedra.
  • In this simulation, FW_H and BroadBand Noise are used for acoustic modeling.
Scaneagle

ScanEagle UAV(Drone) Acoustic Analysis: CFD Simulation by Ansys Fluent

  • The problem numerically simulates a ScanEagle UAV using ANSYS Fluent software.
  • We design the 3-D model with the Design Modeler software.
  • We mesh the model with ANSYS Meshing software. The element number equals 3,213,450 and their type is polyhedra.
  • In this simulation, FW_H and BroadBand Noise are used for acoustic modeling.
Skywalker-X5

Skywalker-X5 UAV(Drone) Acoustic Analysis: CFD Simulation by Ansys Fluent

  • The problem numerically simulates a Skywalker-X5 UAV using ANSYS Fluent software.
  • We design the 3-D model with the Design Modeler software.
  • We mesh the model with ANSYS Meshing software. The element number equals 1,195,030 and their type is polyhedra.
  • In this simulation, FW_H and BroadBand Noise are used for acoustic modeling.
Skywalker-X8

Skywalker-X8 UAV(Drone) Acoustic Analysis: CFD Simulation by Ansys Fluent

  • The problem numerically simulates a Skywalker-X8 UAV using ANSYS Fluent software.
  • We design the 3-D model with the Design Modeler software.
  • We mesh the model with Fluent Meshing  software. The element number equals 928,595 and their type is polyhedra.
  • In this simulation, FW_H and BroadBand Noise are used for acoustic modeling.
Bayraktar Uav

Bayraktar UAV Acoustic Analysis: CFD Simulation by Ansys Fluent

  • The problem numerically simulates a Bayractar UAV using ANSYS Fluent software.
  • We design the 3-D model with the Design Modeler software.
  • We mesh the model with Fluent Meshing software. The element number equals 1,199,753 and their type is polyhedra.
  • In this simulation, FW_H and BroadBand Noise are used for acoustic modeling.

Special Offers For All Products

If you need the Geometry designing and Mesh generation training video for all the products, you can choose this option.
The journal file in ANSYS Fluent is used to record and automate simulations for repeatability and batch processing.
Editable geometry and mesh allows users to create and modify geometry and mesh to define the computational domain for simulations.
The case and data files in ANSYS Fluent store the simulation setup and results, respectively, for analysis and post-processing.
Geometry, Mesh, and CFD Simulation methodologygy explanation, result analysis and conclusion

Special Offers For Single Product

Get a FREE consultation to discuss running your simulations on our high-performance computing systems
If you need the Geometry designing and Mesh generation training video for one product, you can choose this option.
editable geometry and mesh allows users to create and modify geometry and mesh to define the computational domain for simulations.
The case and data files in ANSYS Fluent store the simulation setup and results, respectively, for analysis and post-processing.
Geometry, Mesh, and CFD Simulation methodologygy explanation, result analysis and conclusion
Enhancing Your Project: Comprehensive Consultation and Optimization Services
The MR CFD certification can be a valuable addition to a student resume, and passing the interactive test can demonstrate a strong understanding of CFD simulation principles and techniques related to this product.
The journal file in ANSYS Fluent is used to record and automate simulations for repeatability and batch processing.

Description

Acoustic Analysis; CFD Simulation Training for 6 Projects In One Package

Aerospace science and Aerodynamic perspective are intertwined with our lives today. Now, if we talk about acoustics, it will have a lot of application in various industries. This package will introduce you to the description of various projects and designs and how to simulate them, and it will examine a wide range of related studies numerically.

By preparing this package, you will gain acceptable information and training in the field of Acoustic simulation. Also, if you need Simple Aerodynamic simulation, you can purchase another package that includes this simulation.

Our whole effort in this package has been to teach you the best way to configure Fluent, extract results, and analyze data to help you analyze, design, and build UAVs. Your perspective and performance in this field will change dramatically after viewing this package. The CFD simulation includes 6 different CFD simulation projects using ANSYS Fluent software related to different UAVs, which perform Simple Aerodynamic simulation, Acoustic simulation, obtaining Dynamic Stability Derivatives and FSI simulation for each UAV.

In this package, we have performed an acoustic simulation for each UAV using two BroadBand Noise and Ffowcs Williams and Hawkings (FW_H) models.. This package uses different types of UAVs for tactical, reconnaissance and mapping purposes. The devices used in this training package are:

  • RQ-7 Shadow
  • RQ-11 Raven
  • ScanEagle
  • Skywalker-x5
  • Skywalker-x8
  • Bayraktar

An attempt has been made to select various UAVs based on performance, operating altitude, length, wingspan, etc. to face different challenges in terms of parameters and fluid phenomena.

By studying this amazing and practical training package, you can claim to be an expert in modeling and analyzing any CFD simulation related to fixed-wing and their applications.
