UAV (Drone) FSI Analysis: CFD Simulation by ANSYS Fluent, 6 Projects

Description

FSI Analysis: CFD Simulation Training for 6 Projects In One Package

When designing and building a drone, one of the most important issues to consider is the effect of the fluid on the UAV and the amount of stress and displacement it causes. If these points are not taken into account in the design and construction, our product will not be able to obtain safety approvals. Therefore, it is essential to pay attention to where the most stress occurs and how much it is.

By preparing this package, you will gain acceptable information and training in the field of Fluid Structure Interaction (FSI). Also, if you need Simple Aerodynamic simulation, Acoustic or Stability Derivative Analysis, you can purchase another package that includes this simulation.

Our whole effort in this package has been to teach you the best way to configure Fluent, extract results, and analyze data to help you analyze, design, and build UAVs. Your perspective and performance in this field will change dramatically after viewing this package. The CFD simulation includes 6 different CFD simulation projects using ANSYS Fluent software related to different UAVs, which perform Simple Aerodynamic simulation, Acoustic simulation, obtaining Stability Derivatives and FSI simulation for each UAV.

In this package, we have performed a FSI simulation for each UAV using ANSYS Fluent software. This package uses different types of UAVs for tactical, reconnaissance, and mapping purposes. The devices used in this training package are:

• RQ-7 Shadow
• RQ-11 Raven
• ScanEagle
• Skywalker_x5
• Skywalker_x8
• Bayraktar

An attempt has been made to select various UAVs based on performance, operating altitude, length, wingspan, etc. to face different challenges in terms of parameters and fluid phenomena.

By studying this amazing and practical training package, you can claim to be an expert in modeling and analyzing any CFD simulation related to fixed-wing and their applications.
