DPM Combustion: Combusting Particle and Droplet, 8 Practical Exercises

Original price was: $1,420.00.Current price is: $299.00. Student Discount

  • Advanced DPM combustion package featuring 8 comprehensive ANSYS Fluent exercises, focusing on particle and droplet combustion phenomena.
  • Covers various combustion applications from liquid fuel sprays to biomass combustion and fluidized bed systems.
  • Addresses critical aspects including time-step sensitivity, evaporation modeling, and combustion chemistry.
  • Integrates multiple physics including spray dynamics, heat transfer, and reaction mechanisms.
  • Features industrial applications in power generation, boiler systems, and combustion chambers.
  • Designed for engineers specializing in combustion analysis and thermal system design.
Click on Add To Cart and obtain the Geometry file, Mesh file, and a Comprehensive ANSYS Fluent Training Video.

To Order Your Project or benefit from a CFD consultation, contact our experts via email ([email protected]), online support tab, or WhatsApp at +44 7443 197273.

There are some Free Products to check our service quality.
If you want the training video in another language instead of English, ask it via [email protected] after you buy the product.
Categories: , , , , , , , , , ,
Liquid Fuel

Liquid Fuel Combustion Inside a Chamber Using DPM

  • In this project, liquid fuel combustion is simulated using DPM module.
  • The geometry was designed in SpaceClaim, and a mesh with 769000 elements was generated using ANSYS Meshing.
  • The species transport module is employed.
  • The fuel is ethanol and the oxidizer is nitrous oxide.
Wet Combustion

Wet Combustion Using DPM Combusting Particle

  • The problem numerically simulates the combustion chamber by DPM combusting particle type.
  • We design the 3-D model by the Design Modeler software.
  • We Mesh the model by ANSYS Meshing software.
  • We perform this simulation as unsteady (Transient).
  • We use the Species Transport & DPM model to define the combustion process.
Spray

Combustion Chamber by DPM Spray, CFD Simulation Ansys Fluent Training

  • The problem numerically simulates the combustion chamber by DPM using ANSYS Fluent software.
  • We design the 3-D model by the SpaceClaim software.
  • We Mesh the model by ANSYS Meshing software.
  • We perform this simulation as unsteady (Transient).
  • We use the Species Transport model to define the combustion process.
Time Step Size Effect On Particle Injection In Combustion Chamber, Ansys Fluent Cfd Simulation Tutorial

Time Step Size effect on Particle Injection in Combustion Chamber, ANSYS Fluent CFD Simulation Tutorial

  • The current CFD project simulates the injection of solid particles as fuel inside the combustion chamber via ANSYS Fluent software.
  • We have designed the geometry using ANSYS Design modeler software and created the mesh on this geometry using ANSYS meshing software. The mesh type is Polyhedra with 859,934 cells.
  • The Discrete Phase Model (DPM) determines the particle's movement.
Combustion Chamber

Combustion Chamber with Combusting Particle

  • The problem numerically simulates a combustion chamber with combusting particles using ANSYS Fluent software.
  • We design the 3-D model by the SpaceClaim software.
  • We Mesh the model by ANSYS Meshing software.
  • The mesh type is Structured, and the element number equals 125000.
  • We perform this simulation as unsteady (Transient).
  • We use the Species Transport model to define the combustion process.
  • We use the discrete phase model (DPM) to define Injection into combustion chamber.



Biomass

Biomass Combustion CFD Simulation, ANSYS Fluent Training

  • The problem numerically simulates the biomass combustion process inside a gasifier chamber using ANSYS Fluent software.
  • We design the 2-D model by the Gambit software.
  • We Mesh the model by Gambit software, and the element number equals 1108.
  • We use the DPM model to define spraying the fuel in the chamber as discrete particles.
  • We define Non-Premixed Combustion in the Species model.
  • We use the P1 Radiation model to define radiant heat energy from the flames.
Droplet Evaporation

Diesel-Air Mixture Flow with Fuel Droplet Evaporation

  • This study simulates diesel-air mixture flow with fuel droplet evaporation using ANSYS Fluent CFD software.
  • The 3D cylindrical chamber geometry is designed in SpaceClaim. Meshing is performed using ANSYS Meshing, resulting in over 2 million elements.
  • The Species Transport model with Eddy-Dissipation is employed for turbulence-chemistry interaction.
  • The Discrete Phase Model (DPM) is utilized to simulate fuel droplet movement and evaporation.
Cfb

Circulating Fluidized Bed (CFB) Boiler CFD simulation, ANSYS Fluent

  • In this project, a Circulating Fluidized Bed(CFB) Boiler is simulated using ANSYS Fluent software.
  • The 3-D geometry is designed in spaceclaim then meshed in ANSYS Meshing producing 437,472 unstructured cells.
  • The species transport including volumetric reactions, is taken into account for modeling combustion.
  • The DPM model is used to model the particles.

Special Offers For All Products

If you need the Geometry designing and Mesh generation training video for all the products, you can choose this option.
The journal file in ANSYS Fluent is used to record and automate simulations for repeatability and batch processing.
Editable geometry and mesh allows users to create and modify geometry and mesh to define the computational domain for simulations.
The case and data files in ANSYS Fluent store the simulation setup and results, respectively, for analysis and post-processing.
Geometry, Mesh, and CFD Simulation methodologygy explanation, result analysis and conclusion
If you want training in any language other than English, we can provide you with a subtitled video in your language.

Special Offers For Single Product

If you need the Geometry designing and Mesh generation training video for one product, you can choose this option.
If you need expert consultation through the training video, this option gives you 1-hour technical support.
The journal file in ANSYS Fluent is used to record and automate simulations for repeatability and batch processing.
editable geometry and mesh allows users to create and modify geometry and mesh to define the computational domain for simulations.
The case and data files in ANSYS Fluent store the simulation setup and results, respectively, for analysis and post-processing.
Geometry, Mesh, and CFD Simulation methodologygy explanation, result analysis and conclusion
The MR CFD certification can be a valuable addition to a student resume, and passing the interactive test can demonstrate a strong understanding of CFD simulation principles and techniques related to this product.
Enhancing Your Project: Comprehensive Consultation and Optimization Services
Collaborative Development of a Conference Paper on Cutting-Edge Topics with MR CFD
Collaborative Publication Opportunity: Contribute to an ISI Article and Get Featured in Scopus and JCR-Indexed Journals
If you want training in any language other than English, we can provide you with a subtitled video in your language.

Description

Course Overview

An advanced training program focused on discrete phase combustion modeling (DPM combustion) using ANSYS Fluent, featuring comprehensive coverage of particle and droplet combustion phenomena in various industrial applications.

Fundamental Liquid Fuel Combustion Module

The initial segment (Exercises 1, 3, 4) establishes core concepts through:

– Basic liquid fuel combustion chamber analysis

– Spray combustion fundamentals

– Time-step sensitivity studies in particle injection

This foundation ensures proper understanding of numerical considerations and basic setup procedures.

Advanced Combustion Phenomena

The middle segment (Exercises 2, 5, 7) progresses into more complex phenomena:

– Wet combustion processes

– Combusting particle dynamics

– Fuel droplet evaporation and mixing

These exercises focus on detailed physical processes and their interaction.

Industrial Applications Module

The final segment (Exercises 6, 8) addresses specific industrial applications:

– Biomass combustion systems

– Circulating fluidized bed boilers

– Large-scale industrial combustion systems

Technical Components

The course emphasizes critical skills including:

– DPM model setup and configuration

– Combustion chemistry implementation

– Particle tracking and fate modeling

– Heat transfer analysis

– Species transport modeling

– Turbulence-chemistry interaction

– Numerical stability considerations

Learning Outcomes

Upon completion, participants will master:

– Advanced DPM combustion modeling

– Multi-phase reaction systems

– Spray combustion dynamics

– Industrial system simulation

– Performance optimization techniques

– Result analysis and validation

This course is ideal for combustion engineers, thermal system designers, and CFD analysts working in power generation, industrial furnaces, and combustion system design.
