Rotary Equipment CFD Simulation Training Package: 9 Advanced Projects by ANSYS Fluent

$449.00 $179.60 Student Discount

  • 9 Advanced, industry relevant cases (Pumps, Dryer, Electronic Engine, Brake Disk, Internal and External Gear Pumps)

  • Master MRF (steady) and sliding/dynamic mesh (transient) setups

  • Advanced CFD for Rotary Equipment in ANSYS Fluent from meshing to validation

Click on Add To Cart and obtain the Geometry file, Mesh file, and a Comprehensive ANSYS Fluent Training Video.

To Order Your Project or benefit from a CFD consultation, contact our experts via email (info@mr-cfd.com), online support tab, or WhatsApp at +44 7443 197273.

There are some Free Products to check our service quality.
If you want the training video in another language instead of English, ask it via info@mr-cfd.com after you buy the product.
Categories: , , , , , , , , , , , , ,
Sales Team Website (1022 X 664 Mm)

Rotary Seed Dryer CFD Simulation, Using DPM and Moving Mesh, by ANSYS FLUENT

  • This work presents a CFD–DEM simulation of a rotary seed dryer.
  • Hot air flows through the inclined drum at 350 K while the drum rotates at 20 RPM.
  • Seeds are modeled with the Discrete Phase Model (DPM) coupled with evaporation into H₂O vapor. The Discrete Element Method (DEM) accounts for particle–particle and particle–wall collisions, improving realism of seed motion.
  • Contours of H₂O mass fraction reveal zones of strong evaporation, reaching values up to 0.0026.
  • The combined CFD–DPM–DEM approach shows how airflow, fin mixing, and collisions enhance drying efficiency.
Lobe Pump

Lobe Pump CFD Simulation, ANSYS Fluent Training

  • The problem numerically simulates the Lobe Pump using ANSYS Fluent software.
  • We design the 2-D model with the Design Modeler software.
  • We mesh the model with ANSYS Meshing software, and the element number equals 128,072.
  • We perform this simulation as unsteady (Transient).
  • We use the Dynamic Mesh Model to define deforming and moving zones.
  • We use the user-defined function (UDF) to define the rotational motion of lobes.
Gerotor Pump

Gerotor Pump CFD Simulation, ANSYS Fluent Training

  • The problem numerically simulates the Gerotor Pump using ANSYS Fluent software.
  • We design the 2-D model with the Design Modeler software.
  • We mesh the model with ANSYS Meshing software, and the element number equals 511,82.
  • We perform this simulation as unsteady (Transient).
  • We use the Dynamic Mesh Model to define deforming and moving zones.
  • We use the user-defined function (UDF) to define the rotational motion of gears.
Diaphragm Pump

Diaphragm Pump CFD Simulation, ANSYS Fluent Training

  • The problem numerically simulates the Diaphragm Pump using ANSYS Fluent software.
  • We design the 2-D model with the Design Modeler software.
  • We mesh the model with ANSYS Meshing software; the element number equals 222,986.
  • We perform this simulation as unsteady (Transient).
  • We use the Dynamic Mesh Model to define deforming and moving zones.
  • We use the user-defined function (UDF) to define the reciprocating motion.
Brake

Brake Disk System Conduction Heat Transfer, ANSYS Fluent Simulation Training

In this project, the heat conduction of a brake disk system is modeled and simulated.

Internal Gear Pump (2)

Numerical Investigation of Cavitation Phenomena in a 2D Gerotor Pump Using ANSYS Fluent

  • This study presents a detailed numerical investigation of cavitation phenomena in a gerotor pump using computational fluid dynamics (CFD) simulation
  • The physical modeling incorporated a mixture model for multiphase flow
  • A key aspect of the simulation was the implementation of dynamic mesh capabilities through User Defined Functions (UDFs)
Certificate

Electronic Engine Cooling Enhancement with and without Water Spray Cooling System

  • This project investigates the thermal management of an electronic engine using CFD simulation through ANSYS Fluent software suite
  • The primary objective was to compare the cooling effectiveness of the engine under two conditions: without water spray cooling and with water spray cooling
  • The simulation workflow began with geometry creation in SpaceClaim, followed by mesh generation in ANSYS Meshing.
  • The simulation framework utilised species transport modelling and implemented a two-way coupled discrete phase model (DPM) specifically for water spray simulation
Internal Gear Pump

Internal Gear Pump CFD Simulation, ANSYS Fluent Training

  • The problem numerically simulates the Internal Gear Pump using ANSYS Fluent software.
  • We design the 2-D model with the Design Modeler software.
  • We mesh the model with ANSYS Meshing software, and the element number equals 50,106.
  • We perform this simulation as unsteady (Transient).
  • We use the Dynamic Mesh Model to define deforming and moving zones.
  • We use the user-defined function (UDF) to define the rotational motion of gears.
External Gear Pump

External Gear Pump CFD Simulation, Dynamic Mesh

  • The problem numerically simulates the External Gear Pump using ANSYS Fluent software.
  • We design the 2-D model with the Design Modeler software.
  • We mesh the model with ANSYS Meshing software, and the element number equals 9,254.
  • We perform this simulation as unsteady (Transient).
  • We use the Dynamic Mesh Model to define deforming and moving zones.
  • We use the user-defined function (CG-Motion UDF) to define the rotational motion of gears.

Special Offers For All Products

If you need the Geometry designing and Mesh generation training video for all the products, you can choose this option.
The journal file in ANSYS Fluent is used to record and automate simulations for repeatability and batch processing.
Editable geometry and mesh allows users to create and modify geometry and mesh to define the computational domain for simulations.
The case and data files in ANSYS Fluent store the simulation setup and results, respectively, for analysis and post-processing.
Geometry, Mesh, and CFD Simulation methodologygy explanation, result analysis and conclusion

Special Offers For Single Product

Get a FREE consultation to discuss running your simulations on our high-performance computing systems
If you need the Geometry designing and Mesh generation training video for one product, you can choose this option.
editable geometry and mesh allows users to create and modify geometry and mesh to define the computational domain for simulations.
The case and data files in ANSYS Fluent store the simulation setup and results, respectively, for analysis and post-processing.
Geometry, Mesh, and CFD Simulation methodologygy explanation, result analysis and conclusion
Enhancing Your Project: Comprehensive Consultation and Optimization Services
The MR CFD certification can be a valuable addition to a student resume, and passing the interactive test can demonstrate a strong understanding of CFD simulation principles and techniques related to this product.
The journal file in ANSYS Fluent is used to record and automate simulations for repeatability and batch processing.

Description

1. Introduction

Rotary Equipments are among the most important technologies in modern industry and is widely used across many fields. The umbrella includes both general rotary machines and turbomachinery. Turbomachinery refers to machines that exchange work with a continuously flowing fluid via rotating blade rows, thereby increasing or extracting the fluid’s energy (e.g., turbines, pumps, fans/blowers, compressors). Because turbomachinery requires its own specialized treatment, it is outside the scope of this package and covered separately. In this training, we focus on rotary equipment that is not turbomachinery.

2. Objectives

This package trains you to build and run CFD simulations of a range of Rotary Equipments with an emphasis on Pumps and other industrial devices such as Dryer, Electronic Engine, Brake Disk and also Internal and External Gear Pumps using ANSYS Fluent. You will learn case setup, meshing, and rotating frame strategies, including MRF for steady operation and sliding/dynamic mesh for transient rotation, and you’ll practice post-processing to extract meaningful performance metrics.

3. Summary

In this training package, students will learn advanced CFD simulations for Rotary Equipment and develop the practical skills to set up, solve, and interpret cases through a diverse set of nine hands on examples. The examples span a suitable range of industrial problems, making the curriculum well balanced for learning. By completing these projects, learners will build a reliable workflow from meshing and rotating frame setup (MRF/sliding mesh) to post-processing and validation so they can apply the methods confidently in research and real-world engineering.
