Fan CFD Simulation ANSYS Fluent Training Package

$450.00 Student Discount

This CFD training package is prepared for BEGINNER, INTERMEDIATE, and ADVANCED users of ANSYS Fluent software who are interested in the Fan modules, including 5 practical exercises.

Air Conditioning of an Office by Two Fans Simulation

  • In this project, we have simulated and examined the performance of fan-driven airflow inside an office for HVAC operation, including a computer and four lamps using ANSYS Fluent software.
  • Three-dimensional solar chimney modeling was done using Design Modeler software.
  • The meshing of the model has been done using ANSYS Meshing software and the element number is 207707.
  • The ideal gas equation is opted to capture the changes in the air density and see the buoyant effect due to temperature change.

Split Air Conditioner for Room HVAC CFD Simulation

  • In this project, the HVAC inside a room considering equipment and people is investigated by ANSYS Fluent software, applying two splitters with fans.
  • The 3-D geometry of the present model is carried out using Design Modeler software.
  • The present mesh is done in ANSYS Meshing. The element number is 547820.
  • It should be noted that the ideal gas equation is opted to capture the changes in the air density (buoyancy effect) due to temperature change.
  • The fan pressure jump is defined as a polynomial function.

Fan Heater for HVAC System ANSYS Fluent CFD Simulation Training

  • In this project, we have simulated a fan heater using ANSYS Fluent software for the HVAC of a room.
  • Three-dimensional solar chimney modeling was done using Design Modeler software.
  • The meshing of the model has been done using ANSYS Meshing software and the element number is 207707.
  • The ideal gas equation is opted to capture the changes in the air density (buoyancy effect) due to temperature change.

Greenhouse Air Ventilation CFD Simulation Tutorial

  • The problem numerically simulates the Greenhouse Air Ventilation using ANSYS Fluent software.
  • We design the 3-D model by the Design Modeler software.
  • We Mesh the model by ANSYS Meshing software, and the element number equals 216456.
  • We perform this simulation as unsteady (Transient).
  • We use the Radiation and Convection method for heat transfer.

Fan Stage (Axial Flow) Aerodynamic Performance, ANSYS Fluent Training

  • The problem numerically simulates Fan Stage (Axial Flow) Aerodynamic Performance using ANSYS Fluent software.
  • We design the 3-D model by the Design Modeler software.
  • We Mesh the model by ANSYS Meshing software, and the element number equals 757886.
  • We use the Frame Motion model to define rotational motion.

Special Offers For All Products

If you need the Geometry designing and Mesh generation training video for all the products, you can choose this option.
The journal file in ANSYS Fluent is used to record and automate simulations for repeatability and batch processing.
Editable geometry and mesh allows users to create and modify geometry and mesh to define the computational domain for simulations.
The case and data files in ANSYS Fluent store the simulation setup and results, respectively, for analysis and post-processing.
Geometry, Mesh, and CFD Simulation methodologygy explanation, result analysis and conclusion

Special Offers For Single Product

If you need the Geometry designing and Mesh generation training video for one product, you can choose this option.
If you need expert consultation through the training video, this option gives you 1-hour technical support.
The journal file in ANSYS Fluent is used to record and automate simulations for repeatability and batch processing.
editable geometry and mesh allows users to create and modify geometry and mesh to define the computational domain for simulations.
The case and data files in ANSYS Fluent store the simulation setup and results, respectively, for analysis and post-processing.
Geometry, Mesh, and CFD Simulation methodologygy explanation, result analysis and conclusion
The MR CFD certification can be a valuable addition to a student resume, and passing the interactive test can demonstrate a strong understanding of CFD simulation principles and techniques related to this product.

Description

Fan CFD Simulation ANSYS Fluent Training Package, 5 Practical Exercises

This CFD training package is prepared for BEGINNER, INTERMEDIATE, and ADVANCED users of ANSYS Fluent software who are interested in the Fan modules, including 5 practical exercises. You will learn and obtain comprehensive training on how to simulate projects. The achieved knowledge will enable you to choose the most appropriate modeling approaches and methods for applications and CFD simulations. Fan CFD Simulation ANSYS Fluent Training Package.

Air Ventilation

Project number 1 examines the performance of fan-driven airflow inside an Office for HVAC operation, including a computer and four lamps. On the upper part of two walls of the office, we install two fans to transfer airflow into the office. We also assumed that the doors and windows of the office have convection heat transfer by ambient air. The problem goal is to investigate the effect of blown airflow on the components and people in the office. Also, we simulate the influence of airflow on the heat sources applied in the model.

In project number 2, the movement of the heated airflow inside a Room is investigated. The air inside the room is heated using two split coolers and is distributed inside the space with people, using two fans. A realizable k-epsilon model is exploited to solve turbulent flow equations and the Energy equation is activated to calculate the temperature distribution inside the computational domain. It should be noted that the Ideal Gas equation is opted to capture the changes in air density due to temperature change.

In project number 3, a Fan Heater’s performance and the movement of the heated airflow inside a room are investigated. The air inside the room passes over a heater placed on one side of the room and a fan is responsible to push the heated air into the room. It should be noted that the ideal gas equation is opted to capture the changes in the air density due to temperature change.

In project number 4, which has been done by CFD numerical simulation method, the Air Ventilation is simulated in a GREENHOUSE with two small fans with a radius of 5 cm that rotates at a speed of 100 rad/s. The heat flux of 250 w/m^2 defines the lower wall of the greenhouse, and the sidewalls are defined by a coefficient of 30 and a free stream temperature of 300 K due to the thermal interaction with the outside air convection. In this simulation, the Radiation model is also activated to calculate the effects of radiation on heat transfer.

In project number 5, a Fan Stage is simulated with periodic boundary conditions. The fan stage is a common apparatus used for creating steady airflow in industrial applications used in the cooling process of newly painted body parts. Two sections are involved Rotor and Stator. Rotor, which has a built-in blade, rotates with constant angular velocity and leads air to enter the stator region with high velocity. Blade within the stator alters the flow direction to force it to exit the stator approximately normal to the outlet surface. Rotor domain rotation is simulated using an MRF module with an angular velocity equal to 1800rpm. The stator domain is fixed.

3 reviews for Fan CFD Simulation ANSYS Fluent Training Package

  1. Dr. Stephan Rath II

    How does this package compare to other fan simulation packages on the market?

    • MR CFD Support

      Our package stands out due to its user-friendly interface, accuracy, and the comprehensive training materials provided, including 5 practical exercises.

  2. Carlo Abbott IV

    Is this package capable of simulating both axial and centrifugal fans?

    • MR CFD Support

      Absolutely, the package has been developed to simulate both types of fans – axial and centrifugal, thereby offering an all-inclusive solution for all your fan simulation requirements.

  3. Dr. Leatha Emmerich

    How user-friendly is this package for someone new to fan simulations?

    • MR CFD Support

      The package is designed to be user-friendly, providing a step-by-step guide and practical exercises to help beginners understand and apply fan simulations.
