Dynamic Mesh Training Package, ANSYS Fluent, Part 1, 10 Projects

Original price was: $1,800.00.Current price is: $600.00. Student Discount

Dynamic Mesh ANSYS Fluent Training Package Part 1 is prepared for BEGINNERINTERMEDIATE, and ADVANCED users of ANSYS Fluent software interested in the Dynamic Mesh module, including 10 practical CFD Simulation exercises.

Click on Add To Cart and obtain the Geometry file, Mesh file, and a Comprehensive ANSYS Fluent Training Video.

To Order Your Project or benefit from a CFD consultation, contact our experts via email ([email protected]), online support tab, or WhatsApp at +44 7443 197273.

There are some Free Products to check our service quality.
If you want the training video in another language instead of English, ask it via [email protected] after you buy the product.

Sea Robot Motion Immersed in Water, Dynamic Mesh

  • The problem numerically simulates Sea Robot Motion Immersed in the Water using ANSYS Fluent software.
  • We design the 3-D model by the Design Modeler software.
  • We mesh the model with ANSYS Meshing software, and the element number equals 30010.
  • We perform this simulation as unsteady (Transient).
  • We use the Dynamic Mesh model to apply the location displacement and the shape changes of computational cells.



FSI Analysis for a Ball in Water Flow, ANSYS Fluent CFD Simulation Training

  • The problem numerically simulates the FSI Analysis for a Ball in Water Flow using ANSYS Fluent software.
  • We design the 3-D model with the Design Modeler software.
  • We mesh the model with ANSYS Meshing software, and the element number equals 20192.
  • We perform this simulation as unsteady (Transient).
  • We use Dynamic Mesh to define the mesh deformation.
  • We perform Fluid-Structure Interaction (FSI) to define system coupling between Fluent and Transient Structural.



Submarine Robot motion in a Water Channel, Dynamic Mesh, ANSYS Fluent

The present problem simulates the movement of a submarine robot inside a canal containing water flow using ANSYS Fluent software.

Falling Objects into Water Simulation, Dynamic Mesh, ANSYS Fluent Training

  • The problem numerically simulates the Falling Objects into Water using ANSYS Fluent software.
  • We design the 2-D model by the Design Modeler software.
  • We Mesh the model by ANSYS Meshing software, and the element number equals 8727.
  • We perform this simulation as unsteady (Transient).
  • We use Dynamic Mesh to apply mesh changes over time.
  • We use a UDF is used to define cubes' motion toward the water surface.
  • We use the VOF Multi-Phase model to define water and air.



Oscillatory Wave and its Effect on Fin Motion, ANSYS Fluent CFD Training

  • The problem numerically simulates the Rotational Motion of a Fin under the influence of Oscillatory Wave flow using ANSYS Fluent software.
  • We design the 2-D model by the Design Modeler software.
  • We Mesh the model by ANSYS Meshing software, and the element number equals 120049.
  • We perform this simulation as unsteady (Transient).
  • We use the two-phase VOF model to define the flow field containing the water and air.
  • We use Dynamics Mesh to define deformation of the grid around the moving wall.
  • We determine only one degree of freedom (1-DOF) to rotate the fin.
  • We use a UDF to define the reciprocating motion of the wall that causes the wavy flow.

Floating Vessel Motion in Water by Dynamic Mesh, ANSYS Fluent Training

  • The problem numerically simulates the Floating Vessel Motion in Water using ANSYS Fluent software.
  • We design the 3-D model with the Design Modeler software.
  • We mesh the model with ANSYS Meshing software, and the element number equals 902808.
  • We perform this simulation as unsteady (Transient).
  • We use the Dynamic Mesh model to define the instantaneous change of meshing.
  • We use a UDF to define the motion with two degrees of freedom.
  • We use the VOF Multiphase model and the Open Channel condition to define the water level inside the air.



Submarine Movement in Water by Dynamic Mesh

  • The problem numerically simulates the Submarine Movement in Water using ANSYS Fluent software.
  • We design the 3-D model with the Design Modeler software.
  • We mesh the model with ANSYS Meshing software, and the element number equals 316846.
  • We define the Dynamic Mesh model to define the instantaneous change of meshing.
  • We use a UDF to define the rotational movement.
  • We define a rigid body by considering one degree of freedom.
  • We use the VOF Multi-phase model to define water and air.

Movement of Golf Ball, Impact (Dynamic Mesh), ANSYS Fluent Simulation Tutorial

  • The problem numerically simulates the Movement of a Golf Ball using ANSYS Fluent software.
  • We design the 3-D model by the Design Modeler software.
  • We mesh the model with ICEM software, and the element number equals 945765.
  • We perform this simulation as unsteady (Transient).
  • We use the Dynamic Mesh model to define the motion of the golf ball within the domain.



Darrieus Vertical Axis Water Turbine, Dynamic Mesh, ANSYS Fluent Training

  • The problem numerically simulates the Darrieus Vertical Axis Water Turbine using ANSYS Fluent software.
  • We design the 3-D model with the Design Modeler software.
  • We mesh the model with ANSYS Meshing software, and the element number equals 7422668.
  • We perform this simulation as unsteady (Transient).
  • We use the Dynamic Mesh Model to define the change of meshing around the rotating turbine blades.
  • We define a Rigid Body by a rotational motion with one degree of freedom (1-DOF).

FSI Analysis of Airflow around an Airfoil Vibration

  • The problem numerically simulates the airflow around an airfoil using ANSYS Fluent software.
  • This project is performed by the fluid-structure interaction (FSI) method.
  • We design the 2-D model with the Design Modeler software.
  • We Mesh the model with ANSYS Meshing software, and the element number equals 56220.
  • We perform this simulation as unsteady (Transient).
  • We use the Dynamic Mesh method to consider grid changes over time.
  • We apply the System Coupling to communicate between Fluent and Transient Structural software.
  • We use the Density-based solver to consider compressible flow.
  • We use a UDF to determine variable velocity and attack angle.

Special Offers For All Products

If you need the Geometry designing and Mesh generation training video for all the products, you can choose this option.
The journal file in ANSYS Fluent is used to record and automate simulations for repeatability and batch processing.
Editable geometry and mesh allows users to create and modify geometry and mesh to define the computational domain for simulations.
The case and data files in ANSYS Fluent store the simulation setup and results, respectively, for analysis and post-processing.
Geometry, Mesh, and CFD Simulation methodologygy explanation, result analysis and conclusion
If you want training in any language other than English, we can provide you with a subtitled video in your language.

Special Offers For Single Product

If you need the Geometry designing and Mesh generation training video for one product, you can choose this option.
If you need expert consultation through the training video, this option gives you 1-hour technical support.
The journal file in ANSYS Fluent is used to record and automate simulations for repeatability and batch processing.
editable geometry and mesh allows users to create and modify geometry and mesh to define the computational domain for simulations.
The case and data files in ANSYS Fluent store the simulation setup and results, respectively, for analysis and post-processing.
Geometry, Mesh, and CFD Simulation methodologygy explanation, result analysis and conclusion
The MR CFD certification can be a valuable addition to a student resume, and passing the interactive test can demonstrate a strong understanding of CFD simulation principles and techniques related to this product.
Enhancing Your Project: Comprehensive Consultation and Optimization Services
Collaborative Development of a Conference Paper on Cutting-Edge Topics with MR CFD
Collaborative Publication Opportunity: Contribute to an ISI Article and Get Featured in Scopus and JCR-Indexed Journals
If you want training in any language other than English, we can provide you with a subtitled video in your language.

Description

Dynamic Mesh ANSYS Fluent CFD Simulation Training Package, 10 Practical Exercises, Part 1

Dynamic Mesh ANSYS Fluent Training Package part 1 is prepared for BEGINNERINTERMEDIATE, and ADVANCED users of ANSYS Fluent software interested in the Dynamic Mesh module, including 10 practical CFD Simulation exercises. You will learn and obtain comprehensive training on how to simulate projects. The achieved knowledge will enable you to choose the most appropriate modeling approaches and methods for applications and CFD simulations.

Watery applications

In project number 1, the moving of a cubic Robot in water is simulated. The water enters the inlet boundary with a velocity of 1.5m/s, while the robot moves towards this boundary with a velocity of 3m/s. The dynamic mesh model is activated, enabling smoothing and remeshing options. It should also be mentioned that the robot’s motion is applied to it via a PROFILE.

Project number 2 simulates a spherical ball’s behavior in water using the Dynamic Mesh & FSI method. A computational area is designed as a horizontal tube filled with water flow, So a solid or spherical object in the shape of a ball is immersed in it. In such models, there is a need for instantaneous and time-dependent change in modeling the model based on the type of displacement at the adjacent mesh boundaries. In determining dynamic mesh methods, smoothing and remeshing methods have been used.

Project number 3 simulates the movement of a submarine robot inside a canal containing water flow. The dynamic mesh method has been used to simulate the horizontal movement of this robot inside the channel. In this simulation, a two-dimensional channel is designed to flow at a speed of 1.5 m.s-1. Simultaneously, the robot inside the canal moves horizontally in the water flow path at a speed of 3 m.s-1  to define the instantaneous change of meshing.

In project number 4, Two cubes fall into the liquid. In general, studying objects’ motion in liquids is essential. The cubes’ fall due to gravity’s acceleration helps us understand the sloshing phenomenon. Sloshing occurs when a partially filled reservoir with fluid is subjected to permanent or transient external forces. The liquid’s free surface moves hits the tank walls, and exchanges forces with its wall. These forces may cause problems such as malfunctions in spacecraft.

Project number 5 simulates the fin rotational motion in a two-phase flow field under the influence of the generated oscillatory wave flow. The VOF model defines the two-phase flow used in the problem and consists of two phases. Due to the problem requiring displacement at the model boundaries, a dynamic mesh technique was used to define the fluid flow. Also, the UDF (user-defined function) defines the reciprocating motion of the scaffold wall that causes the waveform within the domain.

Project number 6 simulates the motion of a floating vessel in the water by the dynamic mesh method. In this simulation, a computational domain of water with a specific height level is designed with a floating vessel on the water’s surface. Six degrees of freedom (6-DOF) have also been used to define the type of dynamic mesh behavior; This means that the model can move and relocate in six degrees. The vessel is defined as a floating object on the water surface; the VOF multiphase flow model should be used; So that air is defined in the upper part of the computational domain and water in the lower part.

In the last watery problem, project number 7 simulates the motion of a submarine in the water. In this simulation, a computational domain, including air and water with a certain water level, is designed. Since the submarine has only One degree of freedom (1-DOF) and can only rotate around its central axis (x-axis), and in other degrees, it is constrained and has no transient or rotational motion, we use a UDF for defining this type of movement, considering a degree of freedom. Since the submarine is moving within a computational domain with two water and air phases, the VOF multiphase flow model must be used.

Aerial application

In project number 8, a golf ball movement with an aerodynamic point of view has been studied. The force applied to the ball is equal to 200 N. The golf ball displacement due to the impact has been studied in terms of time.

Project number 9 simulates the water flow around a vertical-axis water turbine (VAWT) submerged using the dynamic mesh method. The water turbine is from vertical axis turbines and is of the Darrieus type. The axis of the turbine is perpendicular to the direction of water flow. The Dynamic Mesh model defines the instantaneous change of meshing around the rotating turbine blades. To define the type of motion of a rigid body, a rotational motion with one degree of freedom (1-DOF) should be specified; Thus, the mass of the blades was considered equal to 1 kg, and the moment of inertia of the blades was considered equal to 3.09 kg.m2. Due to the main nature of the model based on the use of dynamic mesh, the simulation process should be defined as transient (unsteady).

Finally, the last project (number 10) simulates the airflow around an airfoil using the Fluid Solid Interaction (FSI) method. Because this airfoil is moving at a considerable speed, the airflow collides with its body and exerts a force on it. As a result, we can say that a two-way confrontation occurs between the fluid and the solid.
