Rotary Equipment CFD Simulation Training Package: 9 Beginner Projects by ANSYS Fluent

$249.00 $99.60 Student Discount

  • Rotary Equipment CFD Simulation for mixers, centrifuges, Drilling, Bioreactor, Rotary Heat Exchanger, in ANSYS Fluent
  • Learn MRF and Sliding Mesh for steady/transient rotation, model selection, and setup
  • Beginner-friendly projects with industry-relevant Rotary equipments examples and clear reporting templates
Click on Add To Cart and obtain the Geometry file, Mesh file, and a Comprehensive ANSYS Fluent Training Video.

To Order Your Project or benefit from a CFD consultation, contact our experts via email (info@mr-cfd.com), online support tab, or WhatsApp at +44 7443 197273.

There are some Free Products to check our service quality.
If you want the training video in another language instead of English, ask it via info@mr-cfd.com after you buy the product.
Categories: , , , , , , , , , , , , , ,
Rotary Heat Exchanger

Rotary Heat Exchanger, Effect of Mass Flow Rate CFD Simulation

  • The problem numerically simulates a Rotary Heat Exchanger, Effect of Mass Flow Rate on heat transfer coefficient in ANSYS Fluent software.
  • The 2D geometry of the model is created in Design Modeler software.
  • The model is meshed in ANSYS Meshing creating  86,598 elements.
  • The Standard k-epsilon model is used to describe turbulency of the flow.
Rotary Cooling

Rotary Cooling of an object with a Constant Heat Flux, ANSYS Fluent training

The present problem simulates the heat transfer and rotary cooling of a wall under a constant heat flux of a model with a semi cylinder shape, using ANSYS Fluent software.

Powder Distribution

Powder Distribution in Mixer, Transient CFD Simulation

  • This study simulates powder distribution in a stationary fluid after mixing using ANSYS Fluent.
  • The geometry, representing a mixer tank with a rotating propeller, is designed in ANSYS SpaceClaim and meshed using ANSYS Meshing, resulting in 657,330 cells.
  • The simulation is conducted as a transient analysis for a limited time period.
  • The Eulerian multiphase model is employed, with the granular option activated for the powder phase.
  • Mesh motion is enabled to model the propeller rotation at 30 rpm.
Six Blade Stirring Mixer

Six Blade Stirring Mixer CFD Simulation, ANSYS Fluent Training

  • The present problem simulates a Six Blade Stirring Mixer using ANSYS Fluent software.
  • We have designed the geometry using DesignModeler software and created the mesh on this geometry using ANSYS Meshing software. The mesh type is unstructured with 5,447,852 cells.
  • The Mixture multiphase model has been used to simulate the present model.
  • The Multiple Reference Frames (MRF) model is used to simulate the motion of impeller.
  • The solution is steady, and the k-Ꜫ model is chosen to simulate the turbulence of the flow.
Mixer

Mixer Tank CFD Simulation, ANSYS Fluent Training

  • The problem numerically simulates the Mixer Tank using ANSYS Fluent software.
  • We design the 3-D model by the Design Modeler software.
  • We Mesh the model by ANSYS Meshing software, and the element number equals 152641.
  • We use VOF multi-phase model to define 3 phases: air, water and salt.
  • We use the Frame Motion method to define rotational motion for the impeller.



Side Entry Mixing Tank

Side Entry Mixing Tank in 3 Different rotational speeds, Ansys Fluent CFD Simulation Training

In this project, Side Entry Mixing Tank in Different RPM has been simulated and the results of this simulation have been investigated.

Well Drilling

Well Drilling, Mud and Sand Separator, ANSYS Fluent CFD Simulation Training

The present problem simulates well drilling and sludge separation using ANSYS Fluent software.

Centrifuge

Centrifuge CFD Simulation, Two-Phase Flow (MIXTURE), ANSYS Fluent

In this project, the effect of the steady rotation of a centrifugal turbine on a water and air two-phase mixture is investigated.

Bioreactor

Bioreactor Agitated by Rushton Turbine CFD Simulation

  • The problem numerically simulates the Bioreactor Agitated by Rushton Turbine using ANSYS Fluent software.
  • We design the 3-D model by the Design Modeler software.
  • We Mesh the model by ANSYS Meshing software, and the element number equals 3558726.
  • We perform this simulation as unsteady (Transient).
  • We use the Mesh Motion method to define rotational motion.

Special Offers For All Products

If you need the Geometry designing and Mesh generation training video for all the products, you can choose this option.
The journal file in ANSYS Fluent is used to record and automate simulations for repeatability and batch processing.
Editable geometry and mesh allows users to create and modify geometry and mesh to define the computational domain for simulations.
The case and data files in ANSYS Fluent store the simulation setup and results, respectively, for analysis and post-processing.
Geometry, Mesh, and CFD Simulation methodologygy explanation, result analysis and conclusion

Special Offers For Single Product

Get a FREE consultation to discuss running your simulations on our high-performance computing systems
If you need the Geometry designing and Mesh generation training video for one product, you can choose this option.
editable geometry and mesh allows users to create and modify geometry and mesh to define the computational domain for simulations.
The case and data files in ANSYS Fluent store the simulation setup and results, respectively, for analysis and post-processing.
Geometry, Mesh, and CFD Simulation methodologygy explanation, result analysis and conclusion
Enhancing Your Project: Comprehensive Consultation and Optimization Services
The MR CFD certification can be a valuable addition to a student resume, and passing the interactive test can demonstrate a strong understanding of CFD simulation principles and techniques related to this product.
The journal file in ANSYS Fluent is used to record and automate simulations for repeatability and batch processing.

Description

1. Introduction

Rotary equipments are among the most widely used in industry and is highly important within mechanical engineering. In general, it refers to machines that rotate and have a rotating shaft or blades. There is a small but important distinction between general Rotary equipment and turbomachinery. Turbomachinery comprises machines that exchange work with a continuously flowing fluid through rotating blade rows, producing a change in the fluid’s enthalpy. Thus, all turbomachinery belongs to the broader class of Rotary equipment, but not all Rotary equipment are turbomachinery. Many rotating machines transfer energy by positive displacement trapping and moving finite volumes rather than using continuous blade row interaction so they are not turbomachinery .

2. Objectives

In this course, you will master the skills to model, analyze, and simulate the performance of Rotary equipments using ANSYS Fluent. The training strengthens your understanding of rotating equipment and how it differs from turbomachinery, and it introduces both steady and transient rotation setups through MRF and sliding mesh approaches. To ground the concepts, we work through practical examples representative of common rotating equipment such as Mixing tanks, Centrifuges, Drilling, Rotary Heat Exchanger, and Bioreactor so learners can build end to end workflows from setup to post processing with confidence.

3. Summary

Upon completing this course, students will gain a solid, practice-ready foundation in rotating equipment and a clear understanding of how it differs from turbomachinery. Using examples selected for both industrial and academic relevance such as mixing tanks, centrifuges, pumps, electric motors, and dryers learners will practice setting up, simulating, and interpreting results in ANSYS Fluent. Graduates will be able to transfer this knowledge to research and real world engineering work, making sound modeling choices and reporting defensible performance metrics.
