Spray CFD Simulation Training Package, 10 Projects

$480.00 Student Discount

  • Different Spray Applications
  • Different DPM Boundary Conditions
  • Spray Dryer
  • Color Spraying
  • Asthma Spray
  • Air Freshener
  • Combustion Chamber
Click on Add To Cart and obtain the Geometry file, Mesh file, and a Comprehensive ANSYS Fluent Training Video. By the way, You can pay in installments through Klarna, Afterpay (Clearpay), and Affirm.

If you decide to use PayPal to pay, you will get a 5% discount on your order.

To Order Your Project or benefit from a CFD consultation, contact our experts via email ([email protected]), online support tab, or WhatsApp at +44 7443 197273.

There are some Free Products to check our service quality.

If you want the training video in another language instead of English, ask it via [email protected] after you buy the product.
Categories: , , , Tags: , , , , , , , , , , , , , , , , , , , , , , , , , , , ,
Spray Cfd Simulation Using Injection

Spray CFD Simulation using Injection in DPM

  • The problem numerically simulates the process of water spray into a cubic space using ANSYS Fluent software.
  • We design the 3-D model with the Design Modeler software.
  • We mesh the model with ANSYS Meshing software, and the element number equals 25464.
  • We perform this simulation as unsteady (Transient).
  • We use the Discrete Phase Model (DPM) model to define a spray process.
Spray

Spray Dryer ANSYS Fluent CFD Simulation Tutorial

  • In this product, a spray dryer is simulated by ANSYS Fluent software.
  • The geometry of this project has been designed using Desing Modeler software
  • The mesh was created on this geometry using ANSYS Meshing software. The element number is 84047.
  • We have used the Species Transport Model in this simulation.
  • The hot airflow, is responsible for evaporating the moisture in the solution.
Spray

Spray Drying Chamber CFD Simulation by Ansys Fluent

In this project, Spray Drying Chamber has been simulated and the results of this simulation have been investigated.

Spray

Color Spraying on the Wall with Conical Injection

In this project, color spraying on the wall has been simulated and the results of this simulation have been investigated.

Spray

Color Spraying with Wall Film CFD Simulation

In this project, color spraying on the wall with wall film has been simulated, and the results of this simulation have been investigated.

Spray

Air Freshener Spray Device CFD Simulation

  • The problem numerically simulates the Air Freshener Device using ANSYS Fluent software.
  • We design the 3-D model with the Design Modeler software.
  • We mesh the model with ANSYS Meshing software, and the element number equals 357758.
  • We use the discrete phase model (DPM) to define a Spray process.
  • The Species Transport is defined to select Evaporative Droplet injection for particles.
Spray

Air Freshener Spray in Restroom CFD Simulation

  • The problem numerically simulates Air Freshener Spray in the restroom using ANSYS Fluent software.
  • We design the 3-D model by the Design Modeler software.
  • We Mesh the model by ANSYS Meshing software, and the element number equals 1187006.
  • We perform this simulation as unsteady (Transient).
  • We use the Species Transport model to define 3 volumetric species.
  • We use the discrete phase model (DPM) to define spraying air fresheners.
  • We define an injection as the droplet that will be evaporated.



Spray

Inhaler Asthma Spray, CFD Simulation ANSYS Fluent Tutorial

  • The problem numerically simulates the Inhaler Asthma Spray using ANSYS Fluent software.
  • We design the 3-D model by the Design Modeler software.
  • We mesh the model with ANSYS Meshing software, and the element number equals 752277.
  • We use the discrete phase model (DPM) to define a Spray process.
Spray

Asthma Spray Inhaler Injection Into the Lung, Ansys Fluent Training

  • The problem numerically simulates Asthma Spray Inhaler Injection Into the Lung using ANSYS Fluent software.
  • We design the 3-D model by the Design Modeler software.
  • We Mesh the model by ANSYS Meshing software, and the element number equals 3734234.
  • We perform this simulation as unsteady (Transient).
  • We use the Discrete Phase Model (DPM) to define Asthma spray injection into the lung.



Spray

Combustion Chamber by DPM Spray, CFD Simulation Ansys Fluent Training

  • The problem numerically simulates the combustion chamber by DPM using ANSYS Fluent software.
  • We design the 3-D model by the SpaceClaim software.
  • We Mesh the model by ANSYS Meshing software.
  • We perform this simulation as unsteady (Transient).
  • We use the Species Transport model to define the combustion process.

Special Offers For All Products

If you need the Geometry designing and Mesh generation training video for all the products, you can choose this option.
The journal file in ANSYS Fluent is used to record and automate simulations for repeatability and batch processing.
Editable geometry and mesh allows users to create and modify geometry and mesh to define the computational domain for simulations.
The case and data files in ANSYS Fluent store the simulation setup and results, respectively, for analysis and post-processing.
Geometry, Mesh, and CFD Simulation methodologygy explanation, result analysis and conclusion

Special Offers For Single Product

If you need the Geometry designing and Mesh generation training video for one product, you can choose this option.
If you need expert consultation through the training video, this option gives you 1-hour technical support.
The journal file in ANSYS Fluent is used to record and automate simulations for repeatability and batch processing.
editable geometry and mesh allows users to create and modify geometry and mesh to define the computational domain for simulations.
The case and data files in ANSYS Fluent store the simulation setup and results, respectively, for analysis and post-processing.
Geometry, Mesh, and CFD Simulation methodologygy explanation, result analysis and conclusion
The MR CFD certification can be a valuable addition to a student resume, and passing the interactive test can demonstrate a strong understanding of CFD simulation principles and techniques related to this product.

Description

Spray CFD Simulation Training Package, 10 Projects by ANSYS Fluent

Spray CFD Simulation Training Package includes 10 different CFD simulation projects using ANSYS Fluent software related to various Sprays. MR-CFD suggests this package to those interested in Spray CFD analysis. This package introduces you to various project descriptions and designs and how to simulate them, considering numerically a wide range of related studies.

This package includes simulated products using the discrete phase model (DPM). In the discrete phase model, we use the Lagrangian approach for analysis in fluid mechanics. According to this approach, we follow a fluid particle by particle.

The discrete phase model has many industrial applications. One of the main applications of this method is the spray process. The study of spray in different computational models interests engineers and designers.

We start this package with a basic spray product. Product number 1 deals with spray modeling in a specific space.

One of the applications of the spray process is to use it in a spray dryer. These devices are used for drying and dehumidification processes. Products number 2 and 3 are related to the simulation of spray dryers.

In two projects, we have modeled the splash of paint in a certain space. Products number 4 and 5 are related to color spraying.

The difference between these two products is in the boundary conditions of the walls exposed to color dispersion. In project 4, the trap boundary condition is used, and in project 5, the wall film boundary condition is used.

Product number 6 is modeling an air freshener. This device spreads fragrant droplets in space. Product number 7 is the use of air fresheners. This project has investigated the performance effect of air fresheners in a restroom with a heater.

Product number 8 deals with the simulation of the spraying of drug particles in an asthma inhalation device. In product number 9, we presented complementary modeling of asthma devices in medical applications. In this project, we investigated the propagation of inhaled asthma within the bifurcations of the human lung.

In addition, spraying is widely used in combustion chambers. Fuel is injected into the chamber to react with the oxidizer. Product number 10 has focused on the simulation of fuel injection inside a combustion chamber.

By studying this fantastic and practical training package, you can claim you are an expert in modeling and analyzing every CFD simulation related to sprays and their applications. Make yourself ready to enter the related industries as a CFD engineer.
