Heat Exchanger Training Package, Advanced CFD User, 10 Learning Products

• The problem numerically simulates Nano Fluid Heat Transfer in a Porous Heat Exchanger using ANSYS Fluent software.
• We design the 3-D model by the Design Modeler software.
• We Mesh the model by ANSYS Meshing software, and the element number equals 4148881.
• The Energy Equation is activated to consider heat transfer.

• The problem numerically simulates the Solar Heat Exchanger using ANSYS Fluent software.
• We design the 3-D model by the Design Modeler software.
• We Mesh the model by ANSYS Meshing software, and the element number equals 304200.
• We use Discrete Ordinates (DO) and Solar Ray Tracing to consider radiation heat transfer.

In this project, by investigating conjugated heat transfer, the effect of cross-sectional change (with the constant area) on the rate of improvement of heat flux passing through the circular and elliptical finned tube heat exchanger was compared.

• The problem numerically simulates a cross-flow heat exchanger plate panel using ANSYS Fluent software.
• We design the 2-D model with the Design Modeler software.
• We Mesh the model with ANSYS Meshing software.
• The mesh type is Structured, and the element number equals 155000.
• This project is simulated and validated with a reference article.

The present problem validates the article "Heat transfer enhancement of nanofluids in a double pipe heat exchanger with louvered strip inserts" applying CFD simulation, using ANSYS Fluent software.

The present problem simulates heat transfer in a triplex tube heat exchanger containing phase change material (PCM) using ANSYS Fluent software. This simulation is based on the information of a reference article "Internal and external fin heat transfer enhancement technique for latent heat thermal energy storage in triplex tube heat exchangers" and its results are compared and validated with the results in the article.

• The problem numerically simulates Sedimentation and Erosion in a Shell and Tube Heat Exchanger using ANSYS Fluent software.
• We design the 3-D model by the Design Modeler software.
• We Mesh the model by ANSYS Meshing software, and the element number equals 640618.
• We perform this simulation as unsteady (Transient).
• We use Discrete Phase Model (DPM) to define Sand Injection inside the heat exchanger.
• We aim to predict the Erosion Effect by different methods: Finnie, Oka, and Mclaury.

• The problem numerically simulates the shell and tube heat exchanger as a PCM thermal storage system using ANSYS Fluent software.
• We design the 3-D model with the Design Modeler software.
• We mesh the model with ANSYS Meshing software, and the element number equals 169171.
• We define the Solidification and Melting model to define phase change material.
• We use a UDF to define the temperature-dependent viscosity.
• This simulation is validated with a reference article.

• The problem numerically simulates the shell and tube heat exchanger with staggered baffles using ANSYS Fluent software.
• We design the 3-D model with the Design Modeler software.
• We mesh the model with ANSYS Meshing software, and the element number equals 8031342.
• This simulation is validated with a reference article.

In this project, an industrial Shell and Tube has been simulated and the results of this simulation have been investigated.
