Heat Transfer CFD Training Package, ADVANCED User

The present problem simulates a fluid flow with electrical conductivity properties in a simple square chamber.

• This problem simulates the HVAC of an operating room by ANSYS Fluent software.
• The geometry of the present model is drawn by Design Modeler software and then meshed by ANSYS Meshing software.
• It's a Structured mesh, and the cell number equals 938174.
• The VOF multiphase model is used for three phases air, water vapor, and water fluid.
• Mass Transfer is applied to simulate Evaporation/Condensation.
• Also, a UDF file is used to determine the phase change method.

• The problem numerically simulates Chevron Plate Heat Exchanger using ANSYS Fluent software.
• We design the 3-D model by the Design Modeler software.
• We Mesh the model by ANSYS Meshing software, and the element number equals 638892.
• The Energy equation is activated to consider heat transfer in the heat exchanger.

• The problem numerically simulates Non-Equilibrium Porous Aluminum Foam Heat Sink using ANSYS Fluent software.
• We design the 3-D model with the Design Modeler software.
• We Mesh the model with ANSYS Meshing software.
• The mesh type is Structured, and the element number equals 87000.
• This project is simulated and validated with a reference article.
• We use a Porous medium made of aluminum foam.

• The present study examined blood flow in capillaries passing through a tissue containing cancerous tumors using Hyperthermia Therapy by ANSYS Fluent software.
• We have designed the geometry using ANSYS Design modeler software and created the mesh on this geometry using ANSYS meshing software. The mesh type is unstructured with 717087 cells.
• The whole tissue can be considered a porous medium.
• This simulation is performed as unsteady (Transient).
• The Source Term option is used. The UDF code defines the amount of heat applied per volume unit.

• Performance of Phase Change Material (PCM) inside a shell and tube-finned heat exchanger by ANSYS Fluent software.
• The current model is designed in three dimensions using Design Modeler software.
• The meshing of the present model has been done using ANSYS Meshing software. The mesh type is structured, and the element number is 2989887.
• The phase change material is paraffin, so the solidification and melting model has been used.
• The simulation is Unsteady in terms of time.

In this project, the heat conduction of a brake disk system is modeled and simulated.

• The problem numerically simulates the heat transfer inside a mosque using ANSYS Fluent software.
• We design the 3-D model by the Design Modeler software.
• We Mesh the model by ANSYS Meshing software, and the element number equals 674066.
• We use the Rosseland Radiation and Solar Load models on the glass walls.
• We define Heat Source on the floor.

• The problem numerically simulates Radiator Thermal Performance with Fans using ANSYS Fluent software.
• We design the 3-D model with the Design Modeler software.
• We Mesh the model with ANSYS Meshing software, and the element number equals 4683472.
• This project is simulated and validated with a reference article.
• We use the Fan boundary condition and define a Pressure Jump.
• We use a UDF to define the temperature profile.

• The problem numerically simulates the performance of phase change materials (PCM) in a storage tank using ANSYS Fluent software.
• We design the 2-D model by the Design Modeler software.
• We Mesh the model by ANSYS Meshing software.
• The mesh type is Structured, and the element number equals 8200.
• The present project is validated by a reference article.
• We perform this simulation as unsteady (Transient).
• We use the Mixture Multi-Phase model to define air, water and vapor.
• We used a UDF to define a mass transfer between water and vapor, based on surface evaporation.
